Indoor / Outdoor
BBQ Installation
Alfresco Living at its Best
Make the most out of your outdoor living area with a Smart BBQ
In Australia, we like to barbecue rain, hail or shine; summer to winter and everything in-between. There's nothing like the taste of a delicious barbecue whether you're entertaining or just grilling up dinner. And your BBQing just got better with Smart's range of barbecues that can be installed in your enclosed alfresco area.
Our BBQs are certified for installation in enclosed alfresco areas; this is where your area is enclosed by a roof and 3 walls, and the area has 25% natural air ventilation.
When choosing your Smart BBQ, don't forget to install a range hood extractor. This will stop smoke and grease damaging your alfresco area while removing any harmful vapours. Another level of safety is adding an Interlocking system. This will give you peace of mind as it links the extractor fan with the gas BBQ so you can't light your BBQ until the extractor reaches optimum flow.
Click here to see the Alfresco Checklist guide to installing your BBQ
Indoor/Outdoor Installation
Indoor Installation FAQS
Can I build my BBQ into my enclosed alfresco area?
The Smart BBQ Conforms with AS4563 and is suitable for indoor use when installed with an exhaust system complying with AS/NZS1668.1 & AS1668.2 For Australia LPG and Natural Gas Check your local building codes for the proper installation method of installation. In the absence of local codes, this unit should be installed in accordance with AS/NZS 5601 Gas Installation code and SAA Wiring Rules. In particular, refer to AS/NZS 5601 for pipe sizing details. DO NOT use the BBQ in buildings, garages, sheds, breezeway or other such as enclosed areas, without an approved ventilation system.
Who can install my BBQ?
The installation can only be performed by a qualified installer and installed in accordance with AS/NZS 5601 Gas Installation code and SAA Wiring Rules. A qualified electrician is needed to install the required GPO’s for the BBQ, power to hood & to the interlock control
What can I build my BBQ into?
The grill is designed for easy placement into non-combustible material cabinetry., the grill drops into the opening and hangs from its side flanges. A deck is not required to support it from the bottom. Ensure the following minimum clearances to combustible materials:
Why do I need an interlock system and what does it do?
The system acts as an interlock between the ventilation system and the gas solenoid valve. The interlock will isolate the gas supply, in the event that the mechanical ventilation system fails. In addition, the BBQ has a flame failure device fitted meaning if the flame goes out, the gas will be shut off. A high powered rangehood is necessary for this system to function.
What power does the system have?
The unit needs a standard 10amp GPO to facilitate the main power box of the system.
Outdoor Installation FAQS
Where can I install my Smart BBQ?
When determining a suitable location, take into account concerns such as exposure to wind, proximity to traffic paths, and keeping any gas or electrical supply lines as short as possible. Locate the grill only in a well-ventilated area. Never locate the grill inside a building garage, breezeway, shed, or other such enclosure area without an approved ventilation system. During heavy use, the grill will produce a lot of smoke. Ensure there is an adequate area for the smoke to dissipate. This appliance must only be used in an above-ground, open-air situation with natural ventilation, without stagnant areas, where gas leakage and products of combustion are rapidly dispersed by wind and natural convection. Any enclosure in which the appliance is used must comply with one of the following:
Within a partial enclosure that includes an overhead cover and no more than two walls.
Within a partial enclosure that includes an overhead cover and more than two walls, the following shall apply:
Any enclosure with walls on all sides, but at least one permanent opening at ground level, and no overhead cover. DONOT use the barbecue in buildings, garages, sheds, breezeways, or other such enclosed areas. This unit is for Outdoor Use Only!
Check your local building codes for the proper installation method of installation.
In the absence of local codes, this unit should be installed in accordance with
AS/NZS 5601 Gas Installation code and SAA Wiring Rules.
If you are building an Indoor BBQ area, the models you can use indoor are below.
What should I do if I smell gas?
IF YOU SMELL GAS, your installer has not done a proper job of checking for leaks. If the connections are not perfectly sealed, you can have a small leak and therefore a faint gas smell. Finding a leak is not a “do-it-yourself” procedure. Some leaks can only be found with the burner control in the “ON” position. This must be done only by a qualified technician.
What ULPG Bottles should I use with my Smart BBQ?
Only use 9kg approved ULPG bottles. Certain liquid propane dealers may fill liquid propane cylinders for use in the barbecue beyond cylinder filling capacity. This overfilling may create a dangerous condition. Overfilled tanks can build up excess pressure. As a safety device, the tank’s pressure relief valve will vent propane gas vapor to relieve this excess pressure. This vapor is combustible and therefore can be ignited.
To reduce this danger, you should take the following safety precautions:
1. When you have your tank filled, be sure you tell the supplier to fill it to no more than Âľ (75%) of its total filling capacity.
2. If you own or use an extra tank, or have a disconnected tank, you should never store it near or under the barbecue unit or heat box, or near any other ignition or heat source.
Can I use a flexible hose?
If a flexible hose is used to connect to the inlet, it should be as short as possible with a maximum length of 1.5 metres. The supply connection point must be accessible with the appliance installed.
The inner diameters of the pipe are as follows:
- 8 mm for ULPG.
- 13 mm for Natural Gas.
How do I install my Natural Gas Smart BBQ?
If your Smart BBQ is made for Natural Gas. The instillation Shall only be performed by a qualified installer and installed in accordance with AS/NZS 5601 Gas Installation code and SAA Wiring Rules.
IMPORTANT Ensure the following minimum clearances to combustible materials:
What is the minimum distance from the hot plate that I can install my rangehood?
How do I install the electrical components on the Smart BBQ?
Use an approved powerpoint, rated for 240 VAC, 10 Amps, to connect power to the transformer box. Make sure there are no cuts in the insulation to prevent electric shock. See the installation manual for important details.
